Description

The Blackfly® camera line combines Sony CCD, Aptina, e2v, and Sharp sensors with a host of unique features. For FLIR area scan cameras with the latest sensors and most advanced feature sets, please refer to our Blackfly S and Oryx camera families. Model Specifications Resolution 2592 x 1944 Frame Rate 13 FPS Megapixels 5.0 MP Chroma Colour Sensor Name Aptina MT9P031 Sensor Type CMOS Readout Method Rolling Shutter with Global Reset Sensor Format 1/2.5″ Pixel Size 2.2 µm Lens Mount CS-mount ADC 12-bit Exposure Range 0.03 ms to 32 seconds Trigger Modes Standard, bulb, overlapped, multi-shot Partial Image Modes Pixel binning, decimation, ROI Image Processing Gamma, lookup table, hue, saturation and sharpness Image Buffer 16 MB User Sets 2 user configuration sets for custom camera settings Flash Memory 512 KB non-volatile memory Opto-isolated I/O Ports 1 input, 1 output Auxiliary Output 3.3 V, 120 mA maximum Interface GigE PoE Power Requirements 12 V nominal (5 – 16 V) via GPIO interface Power Consumptions (Maximum) 2.5 W Dimensions / Mass 29 mm x 29 mm x 30 mm / 36 grams Machine Vision Standard GigE Vision v1.2 Compliance CE, FCC, KCC, RoHS Temperature Operating: 0° to 45°C Storage: -30° to 60°C (ambient) Humidity Operating: 20 to 80% (no condensation) Storage: 20 to 95% (no condensation)
